Applicable for mid-high viscosity coarse mortar and true stone paint, to mixing, pushing and dispersing the liquid and liquid-solid phase materials.
The Hardened reducer have feature of high torque and vigorous stirring , can pushing the material rolling up and down , and make solid phase dissolved fusion with liquid.
技术参数 Parameter \ 型号 Model 落地或平台式
SJ-15 Floor or platform type落地或平台式
SJ-22 Floor or platform type平台连罐型
SJ-30平台连罐型
SJ-50
主电机功率
Power of Main Motor (kw)18.5 30 37 55
搅拌轴转速
Mixing shaft speed (r.p.m)0-280 0-280 0-280 0-280
搅拌浆形式
Mixing blade diameter (mm)ɸ350 ɸ600 ɸ680 ɸ900
升降行程
Lift (mm)900 1200
适配罐容量
Tank capacity (L)500 1500 2500 5000
升降泵功率
Lift pump power (kw)0.75 1.1
低速刮壁功率 (摆线减速)
Low speed scraper power (cycloidal reducer)(kw)7.5 15
刮壁转速
Scraper speed (rpm)28 28
重量
Weight (kg)1000 1800 2800 4500
