Main features of LS series :
This machine combines both milling and dispersing function. It is easy to operate. maintain, clean, change color, also with low cost. Its speed is controlled by ex-proof stepless inverter which lower the energy consumption and higher the productivity. There is advantage such as no residual, low noisy, no resonace, high stability. It is suitable to mixing and milling in the high, low viscosity paste seperately. The fineness of material can reach to 5-20um according to the grinding time. The machine is with water cooling cycle system that can lower the temperature of grinding material.
Model & specifications: LS3, 10, 20, 30L, 40L
| Model | Grinding basket volume (L) | Main power (kw) | Main shaft speed (r/min) | Zirconium beads (kg) | Viscosity (pa.s) | Maximum output (kg/h) | Fineness (um) | Weight (kg) | Lift (mm) |
|---|---|---|---|---|---|---|---|---|---|
| LS-3 | 3L | 2.2 | 5-1000 | 5 | <2 | 50 | 5-30 | 600 | 510 |
| LS-10 | 10L | 15 | 50-600 | 20 | <2 | 200 | 5-30 | 800 | 950 |
| LS-20 | 20L | 22 | 50-500 | 35 | <2 | 400 | 5-30 | 1200 | 950 |
| LS-30 | 30L | 30 | 50-400 | 50 | <2 | 600 | 5-30 | 1500 | 1200 |
| LS-40 | 40L | 37 | 50-400 | 65 | <2 | 800 | 5-30 | 1800 | 1200 |
